Avant 640i Loader

“600 series” A perfect combination of power and agility.
Avant 600 series is the real all-rounder in the range. It combines power, lift capacity and professional hydraulics which are in a very compact package. This makes 600 series a very popular machine for many professionals in landscaping, groundcare, construction, farming, horse stables, and many other customers. The max. 1,1-tonne lift capacity is just perfect for a multitude of jobs and the powerful auxiliary hydraulics runs almost all Avant attachments. The customers also like the easy transporting of 600 series. Thanks to the compact dimensions it is possible to fit both the loader and the attachments on the trailer, and inside the van if necessary.

600 series customers also benefit from Avant’s telescopic boom, which is a standard feature. Lift height and outreach are excellent for a machine of this size and they can be steplessly adjusted with the teleboom. This guarantees very fast and ergonomic load handling.

The great Avant stability is present in 600 series as well, and the excellent visibility to the attachment and work area is valued by all operators. Avant’s 4×4 hydrostatic drive system gives the best possible traction in all situations.

The comprehensive range of options are available for 600 series also, including all cab options. From over 200 attachments specially designed for Avant loaders the customers can choose the best package for any use.

Media and Downloads

Features

Lift Capacity: 1190kg
Lift Height: 2.8m
Engine Power: 26hp Diesel
Width: 1290mm
Oil Flow: 50 l/min
Weight: 1420kg
Speed: 23 km/h
Tipping Loaad: 1190 kg
Engine: Kohler
Engine Output: 19 kW (26 hp)

Additional Information

LENGTH 2610 mm
WIDTH (with standard wheels) 1290 mm
HEIGHT (with standard wheels) 2060 mm
WEIGHT 1580 kg
STANDARD WHEELS 26×12.00-12″  Grass / TR
TRANSMISSION, DRIVE hydrostatic Avant OptidriveTM
PULLING FORCE MAX. 1000 kp
DRIVE SPEED MAX. 23 km/h
AUX. HYDRAULICS OIL FLOW / PRESSURE 66 l/min 200 bar
TURNING RADIUS INSIDE/OUTSIDE 940 / 2250 mm
MAX. LIFTING HEIGHT 2835 mm
TIPPING LOAD  1190 kg
MAX. BREAKOUT FORCE / 50 CM 1250 kg
ENGINE MAKE AND TYPE Kohler KSD 1403NA Stage V, 3-cyl.
ENGINE OUTPUT (ECE R120) 19 kW (26 hp)
MAXIMUM TORQUE 90 Nm @ 1800 rpm
FUEL Diesel
