Pannkoke Glass Lifter – 7211-DS2 – Dual Circuit

Description

An excellent all rounder, this 600kg capacity dual circuit Kombi 7211-DS2 offers lockable tilting at 15° intervals.

Extension arms and supplementary pads are supplied as standard, giving a 2.8m pad spread for extra stability when handling large pieces of glass. The DS2 features manual rotation through +/- 90° and individual pad shut-off valves to help accommmodate irregular loads.

• Dual circuit vacuum system with 1 pump and 2 vacuum tanks.
• Suitable for lifting gastight materials with a smooth surface for example: glass, plastic boards, ceramic plates, sheet metals, coated boards.
• With 300mm Black rubber suction cups that are not abrasion resistant and heat resistant to 100˚C
• 12 suction cups(14 with extension arms)
• Loading capacity of frame is 600kg vertical and horizontal
• The weight of the lifter is 112kg
• The structural depth of the lifter is 255mm approx.
• 12 volt DC pump from rechargeable battery.
• Battery Charger 110v/240v 50/60Hz single phase.
• 2 x extension arms with moveable pads
