Wacker Neuson Wheel Loader WL32
The WL32 wheel loader is the ideal partner when it comes to handling a wide range of different work tasks. It is well suited to transport material, green area maintenance with a mulcher and mower and especially snow removal services. Because of its compact dimensions, particularly the narrow width of the machine, it can be used with snowplow on sidewalks. With up to 100 l/min hydraulic output, it can efficiently operate demanding attachments such as a snow blower.
Media and Downloads
Features
High hydraulic performance
High-quality powder coating
100 % connectible differential lock
The wheel loader as an attachment carrier
Rear hydraulic connections
Maximum traction thanks to articulated pendulum joint
Efficient change of attachments
Consistent operating philosophy
Ergonomic Joystick
Ergonomic cockpit
Additional Information
| A | Total length | 4,715 mm |
| B | Total length without bucket | 4,022 mm |
| C | Bucket pivot point (to center of axle) | 675 mm |
| D | Wheel base | 1,952 mm |
| E | Rear overhang | 1,290 mm |
| F | Height with operator’s canopy (fixed) | 2,351 mm |
| F | Height with cab | 2,351 mm |
| H | Seat height | 1,354 mm |
| J | Total working height | 3,948 mm |
| K | Bucket pivot point (max. lift height) | 3,208 mm |
| L | Load-over height | 2,890 mm |
| M | Dumping height | 2,300 mm |
| N | Reach (at M) | 265 mm |
| O | Digging depth | 123 mm |
| P | Total width | 1,414 mm |
| Q | Track width | 1,014 mm |
| S | Ground clearance | 275 mm |
| T | Maximum radius | 3,447 mm |
| U | Radius on the outer edge | 3,171 mm |
| V | Inner radius | 1,731 mm |
| W | Articulation angle | 45 ° |
| X | Rollback angle at max. lift height | 56 ° |
| Y | Dumping angle | 37 ° |
| Z | Rollback angle on ground | 46 ° |
