Stump grinder

Avant stump grinder is an efficient and easy to operate tree stump remover. The cutting disc is mounted crosswise in relation to the loader, which means it throws the wood waste to the right side โ€“ the waste doesnโ€™t fly on the operator or the loader. In addition, the stump grinder is equipped with a protective rubber cover which prevents the wood from flying around.

Grinding happens by moving the grinder forward and backward which means easy control with the drive pedals of the loader โ€“ or with the tilt movement of the quick attach plate, and the sideways mounting of the cutting disc guarantees excellent visibility to the working area. Cutting teeth have three cutting edges: once a tooth becomes blunt, its fastening bolt is easy to open and turn the tooth so that a sharp cutting edge comes into use.

Equipped with รธ 540 mm cutting disc with 20 pcs replaceable teeth
Teeth have three cutting edges โ€“ once a tooth becomes blunt it can be turned to get a new sharp cutting edge
Mounted crosswise in relation to the loader: cutting disc throws the wood waste to the right side and the waste doesnโ€™t fly on the loader and the operator
Excellent visibility to the work area, easy to operate
Support bearing on cutting disc, reduces torsion forces
Rubber damper on the quick attach bracket minimizes vibrations to the loader and makes working smoother

More Images & Videos

Technical Information

Cutting disc diameter 540 mm
Number of teeth 20 pcs
Width 840 mm
Height 920 mm
Length 630 mm
Weight 175 kg
Product no. A438282

Options

Heavy duty tooth kit, teeth with tungsten carbide tip A444671

Compatible Models

incompatible icon220
incompatible icon225
incompatible icon225LPG
incompatible icon313S
incompatible icon320S
incompatible icon420
compatible icon423
incompatible icon520
compatible icon523
compatible icon525LPG
compatible icon528
compatible icon530
compatible iconR20
compatible iconR28
very-compatible iconR35
very-compatible icon630
very-compatible icon635
very-compatible icon640
very-compatible icon735
very-compatible icon745
very-compatible icon750
very-compatible icon755i
very-compatible icon760i
very-compatible icon850
very-compatible icon860i
incompatible icone513
incompatible icone527
