ProDem Hydraulic Breakers

The ProDem PRB Series are Vibration Dampened Silenced hydraulic hammers which have been developed for the toughest kinds of environments.

Media and Downloads

Perfect cushion damper

Unique valve design

Centralised lubricating system

Hardened rock claw

High quality working tool

Full box enclosure

Unique valve design - Lessens pressure fluctuation, Less damage on carrier’s pump

Hardened rock claw - Resisting wear and abrasion

Easy maintenance - Fewer components, Wide and appropriate openings

Through bolt - Reduces internal torsion stress to increase fastener life

Model	Working Weight (kg)	Required Oil Flow (lpm)	Operating Pressure (bar)	Impact Energy (max) – Low Speed (joule)	Impact Energy (max) – High Speed (joule)	Impact Frequency – Low Speed (bpm)	Impact Frequency – High Speed (bpm)	Tool Diameter (mm)	Tool Diameter (inch)	Excavator Weight Class (t)
PRB008	75	12-22	100-130	N/A	110	N/A	750-1300	42	1.65	0.7-1.5
PRB010	123	15-25	100-130	N/A	180	N/A	700-1200	45	1.80	0.7-3
PRB030	149	20-35	100-130	N/A	300	N/A	550-1000	50	2.0	1.5-4.5
PRB040	209	30-50	110-140	N/A	450	N/A	550-1000	58	2.3	2.5-6
PRB050	294	35-65	130-170	N/A	700	N/A	550-1000	68	2.7	3.5-8
PRB060	424	45-90	130-170	N/A	1000	N/A	520-1000	80	3.2	5-11
PRB100	537	60-110	140-180	N/A	1350	N/A	500-1000	93	3.7	7-15
PRB150	974	80-140	140-180	2500	2150	380-700	550-850	105	4.1	12-20
PRB170	1270	110-170	160-180	2800	2200	350-600	550-750	117	4.6	14-24
PRB200	1564	100-150	160-180	3500	2800	340-550	440-700	125	4.9	16-25
PRB250	1662	130-180	160-180	4300	3200	330-500	430-650	135	5.3	20-30
PRB300	2492	170-240	165-185	6100	4200	310-490	400-680	150	5.9	26-35
PRB400	3100	200-280	165-185	7600	6000	330-450	420-600	165	6.5	32-45
PRB500	4200	230-330	165-185	10400	7900	250-370	350-500	180	7.1	40-70
PRB700	6700	320-420	165-185	13000	10000	280-370	370-480	205	8.07	60-110
PRB1000	10070	410-530	165-185	17000	14000	260-340	360-470	245	9.65	85-140
