Wacker Neuson Wheel Loader WL44
With the entry-level models by Wacker Neuson, you don’t have to do without – especially when it comes to performance. The durable and sophisticated technology of the WL44 wheel loader has proven itself in many applications. This makes it a particularly reliable performance machine in volume business – a cost-benefit calculation that works out. The WL44 is the perfect machine for material transport.
Media and Downloads
Features
Chassis Operating pressure: 455 bar
Fuel Tank capacity: 82 l
Hydraulic Tank capacity: 66 l
Chassis flow rate: 128 l/min
Hydraulic Flow rate: 58 l/min
Operating pressure: 220 bar
Travel speed: 12.4 mph
Operating Weight: 4,600 kg
Bucker Capacity: 0.85 m3
Additional Information
| A | Total length | 5,420 mm |
| B | Total length without bucket | 4,760 mm |
| C | Bucket pivot point (to center of axle) | 1,040 mm |
| D | Wheel base | 2,110 mm |
| E | Rear overhang | 1,530 mm |
| F | Height with lowered operator’s canopy | 2,332 mm |
| F | Height with operator’s canopy raised | 2,470 mm |
| F | Height with cab raised | 2,528 mm |
| H | Seat height | 1,470 mm |
| J | Total working height | 3,890 mm |
| K | Bucket pivot point (max. lift height) | 3,200 mm |
| L | Load-over height | 2,940 mm |
| M | Dumping height | 2,430 mm |
| N | Reach (at M) | 665 mm |
| O | Digging depth | 136 mm |
| P | Total width | 1,830 mm |
| Q | Track width | 1,500 mm |
| S | Ground clearance | 367 mm |
| T | Maximum radius | 4,270 mm |
| U | Radius on the outer edge | 3,870 mm |
| V | Inner radius | 1,990 mm |
| W | Articulation angle | 40 ° |
| X | Rollback angle at max. lift height | 71 ° |
| Y | Dumping angle | 45 ° |
| Z | Rollback angle on ground | 43 ° |
