Wacker Neuson Wheel Dumper DW50

Wheel Dumper DW50: Optimized for maximum safety and performance

An optimized skip format for even greater water volume and minimized risk of damage when loading and unloading with the excavator bucket, as well as a variety of details that clearly make it outstanding in terms of comfort and safety, make up the DW50. The operator benefits from many storage options, some also lockable, and safety features such as cameras in both directions, rear LED lights incl. dynamic turn signals as well as cruise control and a large clear display. This makes safe work fun.

Media and Downloads

Features

Payload: 5,000 kg
Width: 1,915 mm
Weight: 3,570 kg
Engine: Deutz
Engine Output: 75.3 hp
Travel Speed: 15.5 mp/h
Gradeability: 58%
Length: 4,412 mm
Width: 1,905 mm
Payload: 5,000 k

Additional Information

Speed regulation system

  • The speed regulation system automatically maintains the speed of the machine where possible, provided it is activated. This way, the operator doesn’t have to concentrate on his speed and can enjoy the comfort of automation.

Sturdy skip guard

  • The skip guard protects the operator and the cab from falling material, even while driving.
  • It provides for additional safety even during loading. The protective skip grating was designed and tested for this, based on ISO 10262, front protective grating Level 2.
  • The skip guard can withstand the impact of an excavator bucket with the maximum force of a 15-metric ton excavator.

Auto-stop function

  • The built-in auto-stop function switches the machine off after 5 minutes without use. This period of time can be adjusted and the operator is notified visually and acoustically before switching off.
  • Electrical loads, such as headlights, are also switched off to conserve the machine’s battery. Operating costs are reduced, maintenance intervals are extended and resale value increases.
  • The resulting reduction in engine running time reduces exhaust emissions/CO2.
