Tilt adapter

Avant tilt adapter is mounted between the attachment and the loaderโ€™s attachment coupling plate. With it, the attachment can be tilted sideways and makes it possible to:

Make different forms to the ground with a bucket or leveler
Keep pallet fork level when you are driving on surfaces with gradient
Load pallets that are on uneven ground
Level ground on uneven surfaces
With the 90 degree tilt adapter rotate the attachment as much as 90 ยฐ

More Images & Videos

Technical Information

There are two tilt adapters available:

  1. Tilt adapter with max. 12.5-degree tilting in both directions. It is intended for buckets, leveler and pallet fork โ€“ for jobs where tilting is a must but the tilting angle doesnโ€™t have to be big
  2. Tilt adapter with max. 90-degree rotation, or 45-degree tilting in both directions. It is useful in applications where the attachment needs to be rotated more in order to get the job done: with grabbing tool (rotating of barrels etc.), rock drill, artificial turf attachment (to fit through narrow doors), etc.

The hydraulic cylinder of theย 90 degree tilt adapter canย be mountedย in two different positions, whichย gives two tilting angles: eitherย 45ยฐ tiltingย in both directions, orย 90ยฐ rotationย in one direction.ย Theย tiltย adapterย isย intendedย mainlyย forย non-hydraulicallyย operated attachments,ย butย withย the optional secondย auxiliary hydraulics outletย inย theย frontย itย isย possible toย mount also hydraulically driven attachments like a 4 in 1 bucket, pallet fork with hydraulic fork adjustment, grabbing tool, artificial turf attachment and rock drill at the same time.



  • – Makes it possible to tilt the attachment sideways and e.g. grade the ground with a bucket or leveller, or load pallets on uneven ground with pallet fork
  • – Mounts between the attachment and the quick attach plate of the loader
  • – Two models: with max. ยฑ 12.5ยฐ tilting or with max. 90ยฐ / ยฑ 45ยฐ rotation
Max. tilt +/- 12,5 degrees 90 or +/- 45 degrees
Weight 65 kg 85 kg
Product no A34148 A36505

Options

Compatible Models

compatible icon220 - model A34148
compatible icon225 - model A34148
compatible icon225LPG - model A34148
compatible icon313S - model A34148
compatible icon320S - model A34148
very-compatible icon420 & 423 - model A34148
very-compatible icon520 - model A34148
very-compatible icon523 - model A34148
very-compatible icon525LPG - model A34148
very-compatible icon528 - model A34148
very-compatible icon530 - model A34148
very-compatible iconR20 - model A34148
very-compatible iconR28 - model A34148
very-compatible iconR35 - model A34148
very-compatible icon630 - model A34148
very-compatible icon635 - model A34148
very-compatible icon640 - model A34148
very-compatible icon735 - model A34148
very-compatible icon745 - model A34148
very-compatible icon750 - model A34148
very-compatible icon755i - model A34148
very-compatible icon760i - model A34148
incompatible icon850 - model A34148
incompatible icon860i - model A34148
very-compatible icone513 - model A34148
very-compatible icone527 - model A34148
compatible icon220 - model A36505
compatible icon225 - model A36505
compatible icon225LPG - model A36505
compatible icon313S - model A36505
compatible icon320S - model A36505
very-compatible icon420 & 423 - model A36505
very-compatible icon520 - model A36505
very-compatible icon523 - model A36505
very-compatible icon525LPG - model A36505
very-compatible icon528 - model A36505
very-compatible icon530 - model A36505
very-compatible iconR20 - model A36505
very-compatible iconR28 - model A36505
very-compatible iconR35 - model A36505
very-compatible icon630 - model A36505
very-compatible icon635 - model A36505
very-compatible icon640 - model A36505
very-compatible icon735 - model A36505
very-compatible icon745 - model A36505
very-compatible icon750 - model A36505
very-compatible icon755i - model A36505
very-compatible icon760i - model A36505
very-compatible icon850 - model A36505
very-compatible icon860i - model A36505
very-compatible icone513 - model A36505
very-compatible icone527 - model A36505
