Adapters for mounting 200 series attachments
There are five different adapters available, between std. Avant attachment bracket (Avant 200 series 2, manufactured from 2016-) and 200 series 1 (manufactured 2003-2015)
Case 1: Adapters with Avant 200 series 1 (216/218/220) attachment bracket:
- Weld-on adpater plate with 200 series 1 attachment bracket A46529
- Adapter A33126 that bolts on std. Avant attachment bracket (adapter colour is grey)
- Adapter A36826 that mounts on std. Avant attachment bracket with quick release pins like the attachment coupling plate of the machine. The 200 series 1 attachment bracket is welded on the other side of the adpater (adapter colour is green). This adapter can be useful when you have several attachments with std. Avant attachment bracket and don’t want to mount the A33126 bolt-on adapter on all of them; or when you need to change the attachments often.
For the hydraulic hoses of 200 series 1 attachments you need the A416760 flat face coupling kit. The kit includes 3 pcs flat face quick couplings, their protective caps and the “parking” on the attachment for the attachment hydraulic hoses.
More Images & Videos
Technical Information
Case 2:
You have a 200 series 2 machine (Avant 220/225 – or other Avant model with std. Avant attachment coupling plate), and want to mount on it attachments with 200 series 1 attachment bracket. There are two different adapters available:
1. Adapter A36825 that bolts on 200 series 1 attachment (adapter color is grey)
2. Adapter A35590 that mounts on 200 series 1 attachment with quick-release pin, like the attachment coupling plate of 200 series 1. The std. Avant attachment bracket is welded on the other side (adapter color is green).
This adapter can be useful when you have several 200 series 1 attachments and don’t want to mount the A36825 bolt-on adapter on all of them; or when you need to change the attachments often.
3) Adapter A419705 for hydraulic hoses: on multi connector of the machine, to 200 series 1 attachments with flat face couplings
4) A412129 Hose extension kit, 3 pcs, L=800 mm
* For those 200 series 1 attachments which require longer hoses when mounted on 200 series 2, for example: high tip bucket, mini digger, log grab, auger, lawn mower, collecting mower, all-round grapple
Options
Compatible Models
- Very compatible
- Compatible
- Incompatible
220225225LPG
313S320S420 & 423520523525LPG528530R20R28R35630635640735745750755i760i850855ie513e527
