D450AHG
Versatile, cost-effective and flexible. The D450AHG, with its 4.5-tonne (9,900 lb) payload and 180-degree swing skip, is the dumper with the best payload to price ratio available on the market.
The D450AHG is an all-terrain vehicle which, thanks to the design of its skip, is capable of quickly and easily transporting up to 2,670 litres (4.5 cu ya). Specially designed for major work on every type of terrain, it can meet the most demanding payload requirements, despite its small size.
With its hydrostatic transmission, maximum comfort and safety are assured. Thanks to the transmission brake, it prevents the machine from moving under its own weight on slopes, without you even touching the brake pedal. Also, as there is no need to change gears, the driver can focus on the movements of the machine and its load.
More Images & Videos
Technical Information
General
| Unloading system | Swivel tip |
| Load capacity | 4500 kg |
| Chassis | Articulated |
| Water skip capacity | 1370 l |
| Level skip capacity | 2055 l |
| Heaped skip capacity | 2670 l |
| Empty weight | 2970 kg |
| Transmission | Hydrostatic |
| Reversibility | Non-reversible |
Engine
| Brand | Kubota |
| Model | D1803-CR-T-E5B |
| Power | 32.8 kW |
| Torque | 150,5@1500 |
| No. of cylinders | 3 |
| Emissions | Stage V – EPA Tier 4f |
| Noise level (LwA) | 101 dB(A) |
Driving
| Max. speed | 19 km/h |
| Maximum gradient | 35 % |
| External turning radius | 4830 mm |
| Traction | 4×4 |
| Tyres | 12,0/75-18 |
Hydraulic system
| Hydraulic circuit | 12 cc gear pumps |
| Flow rate | 26.6 l/min |
| Working pressure | 200 bar |
Tank capacity
| Fuel | 44 l |
| Hydraulic system | 40 l |
Brakes
| Service | Hydraulic, sealed, multi-disc |
| Parking | Negative |
Equipment
Driving Position
Rear folding ROPS protective structure
Safety
Seat belt with fasten sensor, Seat with operator’s presence sensor, Acoustic warning for reverse gear, Anti-vandal security system, Negative brake, Rotating beacon, Full visibility camera on the skip side
Lighting & Driving
Rear-view mirror
Comfort
Adjustable ergonomic seat, All-in-one joystick
Advanced equipment
Hydrostatic transmission
Accessories
Water separator diesel filter
